Installing FreeCAD

Step-by-step guide to installing FreeCAD on various operating systems, ensuring you are ready to start designing.

By Kevin McAleer,    2 Minutes

Installing FreeCAD

Getting Ready to Install FreeCAD

Before diving into the installation process, ensure your system meets the necessary requirements. Here’s a quick checklist:

  • Operating System version (Windows, macOS, Linux)
  • Sufficient disk space for installation - Check FreeCAD’s official documentation for specific requirements.
  • Graphics requirements for 3D modeling applications - FreeCAD is not very demanding, but a dedicated GPU can improve performance.

Detailed Installation Steps

Windows

  1. Download the Installer:
  2. Run the Installer:
    • Open the downloaded file and follow the on-screen instructions. Choose whether to install optional components.
  3. Complete Setup:
    • Launch FreeCAD and run initial setup wizards to configure basic settings.

macOS

  1. Download the .dmg File:
    • Navigate to the same download page and select the macOS version.
  2. Install the Application:
    • Drag FreeCAD into your Applications folder and then open it to ensure it runs correctly.

Linux & Raspbery Pi OS

  1. Using Terminal:
    • For distributions like Ubuntu, open your terminal and type: sudo apt install freecad
  2. Verify Installation:
    • Launch FreeCAD from your applications menu to check if it was installed successfully.

Post-Installation Steps

  • Update FreeCAD: Check for the latest updates and apply them.
  • Configure Preferences: Set your preferences for units, language, and default workbenches.

Troubleshooting Installation Issues

  • Permission Errors: Make sure you have administrative access.
  • Failed Installations: Check the error log and consult the FreeCAD forums for specific error messages.

Lesson Assignment

Install FreeCAD following the guidelines for your OS. After installation, open FreeCAD and load a sample project from the welcome screen. Explore basic navigation and tool usage.

Additional Resources
