Securing Your Cluster

Learn how to secure your K3s cluster with role-based access control (RBAC), secrets management, TLS, and best practices for running in a trusted environment.

Kubernetes is powerful — but it’s also complex and needs to be properly secured, even in small or home lab clusters like K3s on Raspberry Pi.

This lesson will walk you through essential security best practices, including RBAC, secrets, TLS, and attack surface reduction.

🛡️ 1. Role-Based Access Control (RBAC)

RBAC controls who can do what in your cluster.

📄 Example: Read-Only User

Create a read-only role and binding:

apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  namespace: default
  name: read-only
rules:
- apiGroups: [""]
  resources: ["pods", "services"]
  verbs: ["get", "list"]
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: read-only-binding
  namespace: default
subjects:
- kind: User
  name: devuser
  apiGroup: rbac.authorization.k8s.io
roleRef:
  kind: Role
  name: read-only
  apiGroup: rbac.authorization.k8s.io

Apply it with kubectl apply -f.

🔐 Use service accounts and OIDC for tighter control.

🔑 2. Secrets Management

Use Secret resources to manage credentials, API tokens, or sensitive configs.

apiVersion: v1
kind: Secret
metadata:
  name: my-secret
type: Opaque
data:
  username: dXNlcg==
  password: c2VjdXJlcGFzcw==

To create secrets from literal values:

kubectl create secret generic my-secret \
  --from-literal=username=user \
  --from-literal=password=securepass

Secrets are base64-encoded, not encrypted. For stronger security, use sealed-secrets or Vault.

🔐 3. Enable TLS (with Ingress)

If you use Traefik or another ingress controller, enable TLS for encrypted connections:

• Use Let’s Encrypt for public domains
• Use self-signed certs or an internal CA for private clusters

Example with cert-manager and Traefik:

kubectl apply -f https://github.com/jetstack/cert-manager/releases/download/v1.13.0/cert-manager.yaml

Then create an Ingress resource with tls: and a Certificate resource.

🧱 4. Secure the K3s API

Best practices:

• Don’t expose 6443 to the internet
• Use firewall rules to allow only internal access

• Remove unused components using --disable flags during K3s install:

  INSTALL_K3S_EXEC="--disable servicelb --disable traefik --disable metrics-server"


🔍 5. Audit & Monitoring

• Enable audit logging in K3s
• Use Falco or Sysdig for runtime security monitoring

• Use kubectl auth can-i to check RBAC rules:

  kubectl auth can-i create deployments --as devuser


🧠 Bonus Tips

✅ Summary

You now know how to:

• Use RBAC to manage user permissions
• Store sensitive data using Kubernetes Secrets
• Protect traffic with TLS via Ingress
• Harden your K3s setup against unauthorized access

Next up: Final Project
