Installing K3s

Install K3s on your Raspberry Pi cluster, configure your master node, and prepare for adding workers.

By Kevin McAleer,    2 Minutes

Page last updated May 24, 2025

Cover

In this lesson, you’ll install K3s on your Raspberry Pi master node, set up the cluster, and prepare for adding worker nodes.

K3s makes Kubernetes installation fast and easy — especially on resource-limited devices like Raspberry Pi.

🚀 Step 1: SSH into the Master Node

From your main computer, SSH into the Pi that will act as the control plane (master):

ssh [email protected]

Replace pi and pi-master.local with your username and hostname or IP if needed.

🧰 Step 2: Install K3s (Master Node)

Run this one-liner:

curl -sfL https://get.k3s.io | sh -

K3s will:

  • Download and install Kubernetes
  • Start systemd service: k3s.service
  • Set up networking with Flannel
  • Create a default service account and kubeconfig

📁 Step 3: Check Cluster Status

After installation:

sudo k3s kubectl get nodes

You should see your master node listed as Ready.

To make kubectl easier to use, copy the K3s kubeconfig to your user’s home directory:

mkdir -p ~/.kube
sudo cp /etc/rancher/k3s/k3s.yaml ~/.kube/config
sudo chown $(id -u):$(id -g) ~/.kube/config

Now you can run:

kubectl get nodes

🔑 Step 4: Get the Join Token

You’ll need a token to join worker nodes to the cluster:

sudo cat /var/lib/rancher/k3s/server/node-token

Copy the token — you’ll use it on the worker nodes in the next lesson.

🧪 Troubleshooting

Problem Solution
k3s.service fails to start Check logs: journalctl -u k3s -e
kubectl not found Use sudo k3s kubectl or set up kubeconfig
Token file missing Confirm you’re on the master node
Network errors Check for cgroup settings and firewalls

📝 Notes

  • K3s uses a built-in SQLite database by default (great for small clusters).
  • For multi-master HA setups, use an external datastore (e.g. MySQL, Postgres, etcd).
  • The default CNI is Flannel, which works well for most local setups.

🎉 Your Kubernetes control plane is now running!

Next up: Adding Nodes
