Adding Nodes
Join additional Raspberry Pi nodes to your K3s cluster using the shared token and master node address.
By Kevin McAleer, 2 Minutes
Page last updated May 24, 2025
With your K3s control plane (master) running, it’s time to expand your cluster by adding worker nodes.
In this lesson, you’ll SSH into each worker Pi and join it to the K3s cluster using a one-liner join command.
🧠 How It Works
Worker nodes use:
- The master node’s IP address
- A shared cluster token
- The
k3s agentservice to register and run workloads
🔑 Step 1: Copy Your Cluster Token
On your master node, run:
sudo cat /var/lib/rancher/k3s/server/node-token
It will look something like:
K108f02c5486e1bdf7a9a7f25a2e7aa3c2c74fa67cced8b31332f5c1b715c962c::server:5bc9c3f0d9249...
Copy this token to use on all worker nodes.
🔧 Step 2: Install K3s Agent on Each Worker Node
On each worker Pi:
-
SSH into the node:
-
Run the installer with the following environment variables:
curl -sfL https://get.k3s.io | K3S_URL=https://<MASTER-IP>:6443 K3S_TOKEN=<YOUR_TOKEN> sh -Replace
<MASTER-IP>and<YOUR_TOKEN>with:- The IP address of your master node (e.g.
192.168.1.100) - The token you copied earlier
- The IP address of your master node (e.g.
✅ Example:
curl -sfL https://get.k3s.io | K3S_URL=https://192.168.1.100:6443 K3S_TOKEN=K108f0... sh -
🧪 Step 3: Verify Node Joined the Cluster
Back on the master node:
kubectl get nodes
You should now see your worker(s) listed:
NAME STATUS ROLES AGE VERSION
pi-master Ready control-plane,master 10m v1.29.2+k3s1
pi-node1 Ready <none> 1m v1.29.2+k3s1
pi-node2 Ready <none> 1m v1.29.2+k3s1
🛠 Additional Notes
- You can repeat this process for as many worker nodes as you want.
- The install script automatically sets up and starts the
k3s-agentsystemd service. - Worker nodes will begin running pods as scheduled by the control plane.
🔍 Troubleshooting
| Issue | Fix |
|---|---|
| Node doesn’t show up | Check firewall/ports (6443 must be open) |
Wrong IP in K3S_URL |
Use master’s static IP, not hostname |
| Token rejected | Double-check the token or regenerate with --token on reinstall |
k3s-agent service fails |
Check logs with journalctl -u k3s-agent -e |
🎉 Your K3s cluster is now multi-node and ready to deploy workloads!
Next up: Troubleshooting Installation
