Encapsulation

Learn about encapsulation in MicroPython and how it hides complexity by exposing only the necessary details.

Encapsulation

In MicroPython, encapsulation is a concept where we hide the complexity of a system by exposing only the necessary details. We achieve this by creating simple interfaces that allow interaction with the code without needing to know its inner workings (see Abstraction).

We can hide properties and methods using access modifiers.

Access Modifiers

An access modifier in MicroPython controls the visibility of properties and methods in a class. These can be public, private, or protected.

In MicroPython, properties and methods are public by default, meaning they can be accessed from outside the class.

Private and Protected

Both class functions and methods can be marked as private (hidden) or protected (restricted from changes).

Private Properties and Methods

Use a double underscore “__” in front of a variable name to make it private:

class Robot:
    __a_private_value = 10

Private methods and properties cannot be accessed from outside the class. Attempting to do so will result in an AttributeError.

Protected Properties and Methods

Use a single underscore “_” in front of a variable name to make it protected:

class Robot:
    _a_protected_value = 20

Protected methods and properties can be accessed from outside the class but should not be changed. This is a convention to indicate that these are intended for internal use only.

Example of Private and Protected Properties and Methods

Below is an example of private and protected properties and methods in a class:

class Robot:
    __battery_max_voltage = 4.2
    __battery_min_voltage = 3.0
    _battery_voltage = 3.7
    __serial_number = "123456"

    def _battery_level(self):
        # Protected method to calculate battery percentage
        battery_percentage = ((self._battery_voltage - self.__battery_min_voltage) / (self.__battery_max_voltage - self.__battery_min_voltage)) * 100
        return int(battery_percentage)

    def battery(self):
        # Public method to get the battery percentage
        return f"{self._battery_level()}%"

r = Robot()
print(r.battery())

In the example above, the complexity of calculating the battery level is hidden. The user doesn’t need to know the voltage levels or the formula used. The __battery_max_voltage and __battery_min_voltage are hidden from the user; IDEs such as Thonny will not suggest them via autocomplete.

If you try to access the r.__battery_max_voltage property from outside the class, you will get an AttributeError.

Also, try changing the r._battery_voltage value; it will work, but it is not best practice.

Name Mangling

What is Name Mangling?

MicroPython does not completely hide or protect these methods and properties; it only makes them harder to access. Name mangling is used to obscure the names of private and protected properties and methods.

Real-World Example

Think of a car. You don’t need to know how the engine works to drive it. You just use the pedals, steering wheel, and gear stick. The engine is abstracted away from you.

Benefits

• Simplicity: Encapsulation simplifies complex systems by hiding unnecessary details.
• Flexibility: We can change the system’s implementation without affecting the code that interacts with it.
• Reusability: Encapsulation allows us to create interfaces that can be reused in different contexts.

Encapsulation and Inheritance also help create abstractions in MicroPython. We will explore these concepts in the following lessons.

Summary

Encapsulation in MicroPython allows us to hide complexity and create simple interfaces for interacting with systems. It helps simplify, add flexibility, and reuse code in our programs.
