Raspberry Pi WireGuard VPN Setup with Docker

What is WireGuard?

WireGuard is a modern VPN protocol that’s lightweight, fast, and easy to configure. It’s designed for simplicity and efficiency, providing secure connections with minimal overhead, making it ideal for low-power devices like the Raspberry Pi.

Why Use Docker on a Raspberry Pi?

Using Docker for WireGuard makes setup and management easier by:

1. Simplifying configuration: Docker encapsulates all dependencies.
2. Enhancing portability: You can replicate the setup on other devices.
3. Ease of use: Docker’s lightweight containerization is perfect for the Raspberry Pi’s limited resources.

Prerequisites

To set up WireGuard on your Raspberry Pi, you’ll need:

1. A Raspberry Pi running Raspberry Pi OS.
2. Docker and Docker Compose installed.
3. A public IP address or Dynamic DNS (DDNS) if using this setup outside your local network.
4. Port forwarding enabled on your router for WireGuard’s UDP port (51820 by default).

Installing Docker on the Raspberry Pi

Step 1: Install Docker

If Docker isn’t already installed, you can do so with:

curl -sSL https://get.docker.com | sh
sudo usermod -aG docker $USER

Reboot your Raspberry Pi to finalize the installation:

sudo reboot

Step 2: Install Docker Compose

Docker Compose will make it easy to manage WireGuard and its configuration. Install it with:

sudo apt update
sudo apt install -y docker-compose

Setting Up WireGuard with Docker Compose

Step 1: Create a Working Directory

Navigate to your preferred directory and create a folder for the WireGuard configuration:

mkdir wireguard-docker && cd wireguard-docker

Step 2: Create a docker-compose.yml File

In this folder, create a docker-compose.yml file:

version: '3.8'

services:
  wireguard:
    image: linuxserver/wireguard
    container_name: wireguard
    cap_add:
      - NET_ADMIN
      - SYS_MODULE
    environment:
      - PUID=1000
      - PGID=1000
      - TZ=Etc/UTC
      - SERVERURL=your_public_ip_or_ddns # Replace with your public IP or DDNS
      - SERVERPORT=51820
      - PEERS=1 # Number of clients
      - PEERDNS=1.1.1.1 # or your preferred DNS
    volumes:
      - ./config:/config
      - /lib/modules:/lib/modules
    ports:
      - 51820:51820/udp
    sysctls:
      - net.ipv4.conf.all.src_valid_mark=1
    restart: unless-stopped

Replace your_public_ip_or_ddns with either your public IP address or a Dynamic DNS hostname if you want access outside your network.

Step 3: Adjusting the Permissions

To make sure Docker has the correct permissions, set the correct user and group IDs:

export PUID=$(id -u)
export PGID=$(id -g)

Starting WireGuard

Run the following command to start the WireGuard container:

sudo docker-compose up -d

The container will generate WireGuard configuration files and keys for each peer, stored in the config folder.

Configuring Your WireGuard Client

Step 1: Locate the Peer Configuration

In the config folder, you’ll find configuration files for each peer (client). Open the configuration file (e.g., peer1.conf).

Step 2: Import the Configuration

On your device (e.g., smartphone, laptop), download the WireGuard app and import the .conf file for your client.

Setting Up Port Forwarding

To access your Raspberry Pi VPN outside your local network, log into your router’s admin page and forward port 51820 (UDP) to your Raspberry Pi’s local IP address.

Testing the VPN Connection

1. Open the WireGuard app on your client device.
2. Toggle the connection on to test your VPN setup.

You should now have secure, encrypted access to your home network via WireGuard!

Managing the WireGuard Container

Stopping the Container

To stop the WireGuard container, run:

sudo docker-compose down

This will stop and remove the container but keep your configuration files.

Restarting the Container

To restart WireGuard, simply run:

sudo docker-compose up -d

Conclusion

With Docker, setting up a secure WireGuard VPN on a Raspberry Pi is simple and efficient. You can now enjoy safe, encrypted access to your network from anywhere in the world.
