Robot Arms

Extend your reach with these robotic arm projects.

16 March 2024
3 minute read

By Kevin McAleer
Share this article on


Table of Contents


  Difficulty:
beginner

  Category:

Robot Arms

Extend your reach with these robotic arm projects.


 16 March 2024   |     3 minute read   |   By Kevin McAleer   |   Share this article on

Videos

For every project I create, I often make a corresponding YouTube video. Sometimes, there might be more than one video for a single project. You can find these videos in this section.

Explore more through these this dedicated videos.

Robot Arms

Building a robot arm is a fun project that can teach you a lot about robotics, electronics, and programming. You can make a simple pick and place robot arm or a complex inverse kinematics robot arm.


Unlock the Future: Building a Robotic Arm at Home

In a world where technology progressively becomes an extension of our capabilities, the fascination with robotics has also grown. Among the marvels of modern engineering is the robotic arm, a type of robot widely used in manufacturing, medical surgery, and even exploration missions to Mars. But what if I told you that you could build your very own robotic arm at home? In this blog post, we take a deep dive into the realm of DIY robotics, starting with a comprehensive workshop on constructing a 3D-printed robotic arm powered by lengths of code and the mathematics of motion.

Robot Arms presentation


The Genesis of a DIY Robotic Arm

Imagine creating a nearly meter-tall robotic arm out of nothing but 3D-printed parts and a blend of software ingenuity. The idea sounds daunting but utterly fascinating. The journey begins with understanding the basics of a robotic arm’s mechanics— a combination of joints and links that mimic the movements of a human arm but with an added measurement of precision and control governed by mathematics and computer code.


The Mechanics Behind the Magic

The robotic arm operates on principles of kinematics, the study of motion without considering the forces that cause it. There are two main types you need to be familiar with: forward and inverse kinematics. Forward kinematics involves setting the positions of the robotic arm’s joints manually and hoping it reaches the desired point. However, the real game-changer is inverse kinematics, which allows you to specify an endpoint, and the system calculates the positions of the joints to reach that point.


The Dance of Geometry and Code

Building a robotic arm significantly involves mathematical calculations, particularly trigonometry from high school. Trigonometry is used in calculating the angles and positions of the arm’s sections, ensuring its movement is precise and aligned with the desired end position.

The complexity increases with the number of joints, as each adds an additional layer of calculations necessary to pinpoint its exact orientation. Yet, with modern technology at our fingertips, these once cumbersome calculations are now made more accessible through programming languages, like Python, which offers libraries to simplify these mathematical operations.

The Robotic Arm: From Design to Reality

The journey from concept to creation involves meticulous planning and designing. In our case, the robotic arm is designed to support a motion control camera, with its structure laid out and segments measured for precise motion control. A combination of software, including Fusion 360 for 3D design (Note - The STL files will be released once I’ve test printed them!) and Google Colab for running Python code, plays a pivotal role in bringing the robotic arm to life. You can find the Google Colab Jupyer notebook code here https://www.github.com/kevinmcaleer/inverse_kinematics

These programs allow not just for the design and mechanical planning of the arm but also for simulating the arm’s motion through interactive notebooks. This iterative process of design, simulation, and testing ensures that the final physical model performs as intended.

The Final Frontier: Building Your Robotic Arm

Constructing your robotic arm is a challenge that requires patience, a firm grasp of mechanics, and coding skills. But it’s also a profoundly rewarding project that paves the way for more advanced robotic creations. Whether it’s for educational purposes, a hobby, or practical applications, building a robotic arm introduces you to the stimulating world of robotics, offering endless possibilities for innovation and creativity.

Embarking on this project also embeds a crucial lesson: the intersection of mechanical engineering and programming is the foundation upon which the future of robotics stands. As we plunge into more advanced territories of AI and machine learning, understanding these core principles is more important than ever.

So, are you ready to unlock the future with your own robotic arm? Let this be the first step on your journey into the fascinating world of DIY robotics.
